Specifications
| Bolt Head Diameter (mm) | 40.00 |
| Bolt Length (mm) | 82.80 |
| Component Number 1.3.004.40 CEEK | |
| Component Number 2. 2.354.32 T4 | |
| Component Number 3.4.004.30 CB86 | |
| Compression Height (mm) | 71.36 |
| Cylinder Bore (mm) | 102.00 |
| Length (mm) | 105.2 |
| Recess Depth 1 (mm) | 19.70 |
| Recess Diameter (mm) | 52.0 |
| Supplementary Article/Info 2 with piston ring carrier | |
| Supplementary Article/Info 2 without cooling duct | |
| Top Land Height (mm) | 14.1 |
Bolt Head Diameter [mm] 40,00, Bolt Length [mm] 82,80, Component Number 1.3.004.40 CEEK, Component Number 2. 2.354.32 T4, Component Number 3.4.004.30 CB86, Compression Height [mm] 71,36, Cylinder Bore [mm] 102,00, Length [mm] 105,2, Recess Depth 1 [mm] 19,70, Recess Diameter [mm] 52,0, Supplementary Article/Info 2 with piston ring carrier, Supplementary Article/Info 2 without cooling duct, Top Land Height [mm] 14,1
