Specifications
| Bolt Head Diameter (mm) | 25.0 |
| Bolt Length (mm) | 68.3 |
| Component Number 1.2.003.60 CEH3 | |
| Component Number 2. 2.003.65 T2 | |
| Component Number 3.4.003.98 CB86 | |
| Compression Height (mm) | 47.2 |
| Cylinder Bore (mm) | 86.5 |
| Length (mm) | 86.2 |
| Piston Clearance (mm) | 0.04 |
| Production Number 86V149 | |
Bolt Head Diameter [mm] 25,0, Bolt Length [mm] 68,3, Component Number 1.2.003.60 CEH3, Component Number 2. 2.003.65 T2, Component Number 3.4.003.98 CB86, Compression Height [mm] 47,2, Cylinder Bore [mm] 86,5, Length [mm] 86,2, Piston Clearance [mm] 0,04, Production Number 86V149
