Specifications
| Bolt Head Diameter (mm) | 22.0 |
| Bolt Length (mm) | 72.0 |
| Component Number 1. 1.50 CE4 | |
| Component Number 2. 1.75 6 | |
| Component Number 3. 4.00 C9 | |
| Compression Height (mm) | 42.75 |
| Cylinder Bore (mm) | 86.5 |
| Length (mm) | 89.4 |
| Piston Clearance (mm) | 0.05 |
| Production Number 85L124 | |
| Recess Depth 1 (mm) | 3.6 |
Bolt Head Diameter [mm] 22,0, Bolt Length [mm] 72,0, Component Number 1. 1.50 CE4, Component Number 2. 1.75 6, Component Number 3. 4.00 C9, Compression Height [mm] 42,75, Cylinder Bore [mm] 86,5, Length [mm] 89,4, Piston Clearance [mm] 0,05, Production Number 85L124, Recess Depth 1 [mm] 3,6
