Specifications
| Component Number 1SBC-318-P | |
| Component Number 2SBC-320-C | |
| Component Number 4SBC-319-C, for bearing clearance from (mm) | 0.054. for housing diameter from [mm] 74.079. for shaft diameter from [mm] 69.812. for wall thickness from [mm] 2.087. to bearing clearance [mm] 0.119. to housing diameter [mm] 74.105. to shaft diameter [mm] 69.825. to wall thickness [mm] 2.100 |
| Width from (mm) | 32.36 |
Component Number 1SBC-318-P, Component Number 2SBC-320-C, Component Number 4SBC-319-C, for bearing clearance from [mm] 0,054, for housing diameter from [mm] 74,079, for shaft diameter from [mm] 69,812, for wall thickness from [mm] 2,087, to bearing clearance [mm] 0,119, to housing diameter [mm] 74,105, to shaft diameter [mm] 69,825, to wall thickness [mm] 2,100, Width from [mm] 32,36
