Specifications
| Component Number 1SBC-474-P0.50 | |
| Component Number 4SBC-473-P0.50, for bearing clearance from (mm) | 0.059. for housing diameter from [mm] 80.416. for shaft diameter from [mm] 76.162. for wall thickness from [mm] 2.333. to bearing clearance [mm] 0.114. to housing diameter [mm] 80.442. to shaft diameter [mm] 76.175. to wall thickness [mm] 2.341 |
| Width from (mm) | 36.7 |
Component Number 1SBC-474-P0.50, Component Number 4SBC-473-P0.50, for bearing clearance from [mm] 0,059, for housing diameter from [mm] 80,416, for shaft diameter from [mm] 76,162, for wall thickness from [mm] 2,333, to bearing clearance [mm] 0,114, to housing diameter [mm] 80,442, to shaft diameter [mm] 76,175, to wall thickness [mm] 2,341, Width from [mm] 36,7
